Typical specification

Insert loss

0.2dB

Return loss

≥55dB (SM)

≥65dB(APC)

≥35dB(MM)

Mating Durability

Max.0.2dB change, 500 mating cycles

Temperature

Max.0.3dB change,-40℃-85℃

Receptacle retention force

2-5.9N

Pull out force

70N

Color

Blue(PC,SM), Green(APC), Beige(MM), Aqua(OM3/OM4)

Optionals

Housing material

Moulded thermoplastic(P)

Die cast metal(DM)

Stainless steel(SS)

Sleeve material

Zirconia Ceramic(ZC)

Phosphor-Bronze(PB)

Fiber type

SM(9/125)

MM(50/125,62.5/125)

Polishes

PC

APC

UPC

Mounting options

Stainless steel spring plate

M2x6 Screw

Both
